The CRY575L microphone power supply is a two-channel unit designed to deliver reliable power for microphones. Each channel provides a necessary constant voltage source for single-ended preamplifiers. It has high input impedance, low output resistance, extremely low background noise and a wide frequency response range.
The CRY575L offers gain options of 0dB(×1) and +20dB(×10) for output signals. Its BNC interface ensures straightforward and user-friendly connectivity.
| Output Impedance | 100Ω |
|---|---|
| Frequency Response Range | 10Hz to 60kHz (±0.5dB) |
| Operating Voltage | 24V |
| Input Interface | DB9 |
| Operating Temperature | -30 to +70℃ (-22 to +158℉) |
| Input Impedance | 1MΩ |
| Output interface | BNC |
